3 Years Warranty Automatic Sliding Door Operator 280*100*90mm 1X300kg/2X150kg

small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  3 Years Warranty Automatic Sliding Door Operator 280*100*90mm 1X300kg/2X150kg Get Best Price

Product Details:
Place of Origin: Zhejiang, China
Brand Name: CIROLLA
Certification: CE/CCC/ SGS
Model Number: 4008
Payment & Shipping Terms:
Minimum Order Quantity: 50pcs
Price: 25usd/pc
Packaging Details: 10pcs/carton, weight 2.25kg
Delivery Time: 7working days
Payment Terms: T/T,L/C, Western Union
Supply Ability: 1000pcs/day
Detailed Product Description
Motor Type: Brushless Door Type: Sliding Doors
Dimension: 280*100*90mm Safety Detection: Automatic Stop /Reverse During Opening Or Closing
Door Weight: 1X300kg/2X150kg Door Width: 650~1600mm
Voltage&Power: 24VDC 75W
High Light:

Sliding Door Motor 75W


Brushless Gear Sliding Door Motor


Sliding Door Motor 24VDC

CE approved 3years Warranty Brushless Motor Automatic Sliding Door Operator
1. Excellent DC24V 75W/100W brushless motor
2. Automatic Sliding Door Operator
3. Digital controller
4. Excellent anti-pinch and anti-thef


1. Operation
The automatic door operator is to be fully electronic operator, housed in a fully anodised aluminum transom section.

2. Controller
The intelliget controller unit can be programmed for connection to any security/alarm systems, is self monitoring and calibrating, has memory for all data on door stoke and brake positions.
3. UPS
The operator has built-in uninterrupted power supply (Battery back up) operation and security during power failure.
4. Belt Drive
Drive is by way of toothed belt, which is reinforced with fiberglass tensile members, and has nylon facing surface for tooth protection on the pulleys. This combination produces silent accurate operation.
5. Tracking

 The track is self-cleaning duel linear. The upper track is made of harder stronger alloy 6351T6, and can be replaced without moving the transom. The wheel trolley is fitted with anti-rise wheels, resulting in very firmly fitted doors with operation free of any racking.
6. Locking
Electromechanical Locking: An electric lock option is available to give total security and can be adapted where manual locking cannot be achieved, i. E. Frameless toughened Glass doors. Lock is the microprocessor controlled electric locking system. The microprocessor monitors all aspects of the lock functions. E. G. To ensure the door is fully closed when the lock is 100% engaged. Terminal outputs are available to signal to security system both door positions and lock status.

7. Safety feature: Moving doors will automatically reverse when traveling in either direction, if obstructed, sensitivity setting to be programmable.
During a power failure or emergency the Failsafe device will fully open the doors. The failsecure mode will close and secure the doors until power is restored

 Competitive Advantages:

1. Advanced machines and professional manager system.
2. Manufacture and supply good quality automatic door MOTORs
3. With ISO 9001 Certification and many others certifications
4. Excellent DC brushless motor , high wear-resistant qualities wheels and reasonable structure design makes it more stable, quiet, longer life
5. Our Service system is perfect
Door specifications:

Door type single door double door
weight of door <=200kg <=150kg*2
opening direction optional optional
Door Width 700-2000mm 600-1800mm
power AC220-250V   50-60HZ
open time 0.5-10S (adjustable)
opening speed <=400mm/s <=400mm/s
closing speed <=300mm/s <=300mm/s
manual force <=50N <=50N
motor DC 24V 75W/100W brushless motor
controller  8 digital Micro-computer processing controller
temperature -30~+50°C
humidity 35-85%RH/No dew 35-85%RH/No dew

Our production line:
3 Years Warranty Automatic Sliding Door Operator 280*100*90mm 1X300kg/2X150kg 0
Our package:
3 Years Warranty Automatic Sliding Door Operator 280*100*90mm 1X300kg/2X150kg 1
