Product Details:
Payment & Shipping Terms:
|
| Commutation: | Brush | Voltage&Power: | 24VDC, 60W |
|---|---|---|---|
| Color: | Black Or Golden | Output Speed: | 250rpm |
| Door Weight: | 1X200kg/ 2X150kg | Function: | Automatic Sliding Door Operators |
| Encoder Available: | 1 Signal, 40pulse, Honeywell Brand | ||
| Highlight: | 250rpm Brush Gear Motor,Micro Computer Brushless Gear Motor,60W Brushless Gear Motor |
||
60W 24V DC Brush Gear Motor for Automatic Sliding Doors
Description:
1) Automatic sliding door control system
2) for frame doors and frameless doors
3) CE Certificate
4) 2years warranty
5) 220-250V power supply
Motor Specifications:
|
Type |
Brush |
|
Voltage |
24VDC |
|
Power |
60W |
|
No load Speed |
250rpm |
|
No load Current |
0.7A |
|
On load Speed |
200rpm |
|
On load Current |
3.5A |
|
Stall torque |
12Nm |
|
Protection class |
IP44 |
|
Weight |
1.5kg |
|
Encoder Honeywell |
1signal,40pulse |
Automatic Sliding Door Specifications:
| Door type | Single door | Double door |
| Weight of door | <=200kg | <=150kg*2 |
| Opening direction | optional | optional |
| Door Width | 700-2000mm | 600-1800mm |
| Power | AC 220-250V 50-60HZ | |
| Open time | 0.5-10S (adjustable) | |
| Opening speed | <=400mm/s | <=400mm/s |
| Closing speed | <=300mm/s | <=300mm/s |
| Manual force | <=50N | <=50N |
| Motor | DC 24V 60W/100W brush motor | |
| Controller | Micro-computer processing controller | |
| Temperature | -30~+50°C | |
| Humidity | 35-85%RH/No dew |
35-85%RH/No dew |
Production Line:
