75RPM High Efficiency Automatic Garage Door Opener replacement with Motor 24VDC

China 75RPM High Efficiency Automatic Garage Door Opener replacement with Motor 24VDC supplier

Large Image :  75RPM High Efficiency Automatic Garage Door Opener replacement with Motor 24VDC

Product Details:

Place of Origin: Zhejiang, China
Brand Name: CIROLLA
Certification: CE/CCC/ SGS
Model Number: 8034

Payment & Shipping Terms:

Minimum Order Quantity: 500PCS
Price: Negotiation
Packaging Details: Standard export carton or pallet,10pcs/carton, weight 1.5kg
Delivery Time: 25-30days
Payment Terms: T/T,L/C, Western Union
Supply Ability: 50,000pcs/month
Contact Now
Detailed Product Description
Operating Speed: High Speed Motor Type: Worm Gear Reduction
Function: Control Gear Material: Nylon
Structure And Working Principle: Brush Application: Universal, Industrial, Household Appliances, Machine Power System





75RPM High Efficiency Automatic Garage Door Opener with Motor 24VDC Smooth Working



Description:



The typical electric garage door opener consists of a power unit that contains the electric motor. The power unit attaches to a track. A trolley connected to an arm that attaches to the top of the garage door slides back and forth on the track, thus opening and closing the garage door. The trolley is pulled along the track by a chain, belt, or screw that turns when the motor is operated.





Specifications:

Motor Data:



Type

Brush

Voltage

24VDC

Power

≥70W

No load Speed

75rpm

No load Current

1.4A

On load Speed

62rpm

On load Current

5.0A

Full torque

7Nm

Stall torque

25Nm

Gear material

DuPont 100P

Protection class

IP44

Weight

1.5kg







Applications:

 Applicable to all kinds of Automatic garage door system: Chain drive and Overhead Garage door.



75RPM High Efficiency Automatic Garage Door Opener replacement with Motor 24VDC75RPM High Efficiency Automatic Garage Door Opener replacement with Motor 24VDC





Characteristic curves of motor:



75RPM High Efficiency Automatic Garage Door Opener replacement with Motor 24VDC

State

Voltage

Current

Pin

Torque

Speed

Pout

Eff

V

A

W

N.m

rpm

W

%

Speed_max

24.03

1.391

33.43

0.17

76.9

1.38

4.1

Eff_max

24.00

5.269

126.4

7.16

62.5

46.85

37.0

Pout_max

24.00

10.64

255.6

16.44

43.3

74.55

29.1

Torque_max

24.00

17.91

430.1

26.69

8.5

23.75

5.5

End

24.00

18.69

448.8

26.54

0.0

0.00

0.0




Competitive Advantage:



The garage door, including its automatic opener system, is the largest appliance in the home. The garage door seals the garage from the elements and provides safety by sealing the garage from people or animals at the exterior.

1. Digital display & easy programming;

 2. Remote control with rolling code;

 3. Soft start & stop, powerful, low noise;

 4. Self-lock function;

 5. Reverse function when meeting obstacle;

 6. Door Unclosed alarm & automatic door closing function.



Outline drawings of motor:



75RPM High Efficiency Automatic Garage Door Opener replacement with Motor 24VDC
