Dunkermotoren Sliding Door Operator Brush Motor 60W Black Or Golden

China Dunkermotoren Sliding Door Operator Brush Motor 60W Black Or Golden supplier
Dunkermotoren Sliding Door Operator Brush Motor 60W Black Or Golden supplier Dunkermotoren Sliding Door Operator Brush Motor 60W Black Or Golden supplier Dunkermotoren Sliding Door Operator Brush Motor 60W Black Or Golden supplier

Large Image :  Dunkermotoren Sliding Door Operator Brush Motor 60W Black Or Golden

Product Details:

Place of Origin: Zhejiang, China
Brand Name: CIROLLA
Certification: CE/CCC/ SGS
Model Number: 4002

Payment & Shipping Terms:

Minimum Order Quantity: 300pcs
Price: 20usd/pc
Packaging Details: 10pcs/carton, weight 2.0kg
Delivery Time: 15days
Payment Terms: T/T,L/C, Western Union
Supply Ability: 1000pcs/day
Contact Now
Detailed Product Description
Commutation: Brush Voltage&Power: 24VDC, 60W
Color: Black Or Golden Output Speed: 250rpm
Door Weight: 1X200kg/ 2X150kg Function: Automatic Sliding Door Operators
Encoder Available: 1 Signal, 40pulse, Honeywell Brand

Brush motor for Sliding Glass doors Dunkermotoren's for sliding door operator 60W 24VDC


Description:

1)Automatic sliding door control system
2)for frame doors and frameless doors
3)CE Certificate
4)2years warranty
5)220-250V power supply



Competitives:

  • Longer life than commutated motors from other manufacturers
  • Low detent torques
  • High efficiency
  • High dynamic acceleration
  • Good regulation characteristics
  • High power density
  • Maintenance-free
  • Robust design
  • Low moment of inertia
  • Motor insulation class E
  • Winding insulation class F
  • Extremely high short time overload capacity of the motor
  • Surface protection
  • Minimum interference radiation, optional interference versions
  • Protection up to IP 65
  • High quality due to fully automated production lines


Motor Specifications:

Type

Brush

Voltage

24VDC

Power

60W

No load Speed

250rpm

No load Current

0.7A

On load Speed

200rpm

On load Current

3.5A

Stall torque

12Nm

Protection class

IP44

Weight

1.5kg

Encoder Honeywell

1signal,40pulse


Automatic Sliding Door Specifications:

Door type Single door Double door
Weight of door <=200kg <=150kg*2
Opening direction optional optional
Door Width 700-2000mm 600-1800mm
Power AC 220-250V   50-60HZ
Open time 0.5-10S (adjustable)
Opening speed <=400mm/s <=400mm/s
Closing speed <=300mm/s <=300mm/s
Manual force <=50N <=50N
Motor DC 24V 60W/100W brush motor
Controller   Micro-computer processing controller
Temperature -30~+50°C
Humidity 35-85%RH/No dew

35-85%RH/No dew


Dunkermotoren Sliding Door Operator Brush Motor 60W Black Or Golden
Dunkermotoren Sliding Door Operator Brush Motor 60W Black Or Golden



Production Line:
Dunkermotoren Sliding Door Operator Brush Motor 60W Black Or Golden





 Dunkermotoren Sliding Door Operator Brush Motor 60W Black Or Golden
